i1300 Plus Series Scanners
Specifications
Recommended Daily Volume
Up to 5,000 pages per day
Throughput Speeds
(portrait, letter size)
Bitonal/grayscale: Up to 60 ppm/120 ipm at 200 dpi
Color: Up to 40 ppm/80 ipm at 200 dpi
(Throughput speeds may vary depending on your choice of driver, application software, operating system and PC.)
Scanning Technology
i1310 Plus: Single CCD; i1320 Plus: Dual CCD; Grayscale output bit depth is 256 levels (8 bits)
Color capture bit depth is 48 bits (16 x 3); Color output bit depth is 24 bits (8 x 3)
Optical Resolution
600 dpi (1200 dpi A4 flatbed accessory)
Illumination
Dual fluorescent (cold cathode)
Output Resolution
75, 100, 150, 200, 240, 300, 400, 600 and 1200 dpi
Max./Min. Document Size
215 mm x 863 mm (8.5 in. x 34 in.)/50 mm x 63.5 mm (2 in. x 2.5 in.)
Paper Thickness and Weight
34-413 g/m
2
(9-110 lb.) paper; ID card thickness: up to 1.25 mm (0.05 in.)
Feeder
Up to 75 sheets of 75 g/m
2
(20 lb.) paper; handles small documents such as ID cards, embossed cards and insurance cards
Multi-feed Detection
With ultrasonic technology
Connectivity
USB 2.0 (cable included)
Bundled Software
TWAIN, ISIS, WIA Drivers; Kodak Capture Desktop Software, Smart Touch; Nuance ScanSoft PaperPort and
OmniPage. Linux SANE and TWAIN Drivers available from www.kodak.com/go/scanonlinux.
Imaging Features
(in the scanner)
Perfect Page Scanning; iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; aggressive
cropping; electronic color dropout; dual stream scanning; interactive color, brightness and contrast adjustment;
automatic orientation; automatic color detection; background color smoothing; image edge fill; image merge; content
based blank page detection; streak filtering; image hole fill; sharpness filter
File Format Outputs
Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF
Warranty (US and Canada)
One-year warranty
Accessories
Kodak white imaging background accessory (front); Kodak A3 Flatbed (black background) Accessory with 1.8-meter
(6 ft.) cable; Kodak A4 Flatbed (white background) Accessory with 1.8-meter (6 ft.) cable; Optional A4 flatbed black
imaging background accessory
Electrical Requirements
100-240 V (International); 50-60 Hz
Power Consumption
Scanner: Off mode: <4 watts; Running: <35 watts
Scanner with A3 Flatbed: Off mode:
≤6 watts: Running: <65 watts
Scanner with A4 Flatbed: Off mode:
≤6 watts: Running: <57 watts
Environmental Factors
Energy Star qualified scanners, Operating temperature: 10-35° C (50-95° F), Operating humidity: 15% to 76% RH
Acoustical Noise (operator
position sound pressure level)
Off mode: <30 dB(A)
Operating mode: <58 dB(A)
Kodak Capture Desktop Software
Recommended PC Configuration
For documents up to 660 mm (26 in.) long at 400 dpi: Intel Core2, 2 GHz Duo Processor or equivalent, 2 GB RAM
Kodak Capture Desktop Software Download
For longer documents/higher resolutions: Intel Core2, 2 GHz Duo Processor or equivalent, 4 GB RAM
Note: for optimal performance when using a PC running the Windows 7 operating system, at least 3 GB RAM
is recommended.
Supported Operating Systems
Windows XP SP2 and SP3 (32-bit), Windows XP x64 edition SP2, Windows Vista SP1 (32-bit and 64-bit),
Windows 7 (32-bit and 64-bit), Windows 2003 Server and 2008 Server x64 Editions, Linux Ubuntu 8.04,
Fedora 9, SUSE 11
Approvals and Product
Certifications
AS/NZS 3548 Class B (C-Tick Mark), CAN/CSA-C22.2 No. 60950-1-03 (C-UL Mark), Canada ICES-003
Issue 3 (Class B), GB4943, GB9254 (Class B), GB 17625.1 Harmonics (CCC “S&E” Mark), EN 55022 ITE
Emissions (Class B), EN 61000-3-3 Flicker, EN 55024 ITE Immunity (CE Mark), EN 60950 (TUV GS Mark),
IEC 60950, CISPR 22 (Class B), VCCI (Class B), CNS 13438 (Class B), CNS 14336, (BSMI Mark), UL 60950-1
(UL Mark), CFR 47 Part 15 Subpart B (FCC Class B), Argentina S-Mark
Consumables Available
Feed module, separation module, feed rollers, roller cleaning pads, Staticide Wipes
Dimensions
Weight: i1310 Plus: 5.2 kg (11.5 lbs.), i1320 Plus: 5.5 kg (12 lbs.)
Depth: 162 mm (6.3 in.) not including input tray and output tray
Width: 330 mm (13 in.)
Height: 246 mm (9.7 in.) not including input tray
©Kodak, 2010. Kodak is a trademark of Kodak.
Specifications are subject to change without notice.
A-5763 CAT No. 133 3640 Printed in USA 3/10
Eastman Kodak Company
343 State Street, Rochester, NY 14650
1-800-944-6171
Kodak Canada, Inc.
Kodak Capture Pro User Manual
Toronto, Ontario M9R 0A1
1-800-465-6325
Service & Support
To learn more:
www.kodak.com/go/i1300Plus
